Circuit breaker VigiComPact NSX160B, 25 kA at 415 vac, MicroLogic 2.2 trip unit 160 a, add-on Vigi mh module, 4P 4d - LV430995

Electricité et domotique, Tableau électrique, Disjoncteur modulaire, Déclencheur pour disjoncteur

Description produit

Main range : ComPact product name : ComPact NSX range of product : ComPact NSX100...250 device short name : VigiCompact NSX160B product or component type : Circuit breaker with Vigi add-on device application : Distribution poles description : 4P protected poles description : 3t 3t + N/2 4t neutral position : Left [In] rated current : 160 A at 40 °C [Ue] rated operational voltage : 440 V AC 50/60 Hz network type : AC network frequency : 50/60 Hz suitability for isolation : Yes conforming to EN/IEC 60947-2 utilisation category : Category A breaking capacity : 15 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2 20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 25 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 40 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 Breaking capacity code : B 25 kA 415 V AC trip unit name : Micrologic 2.2 trip unit technology : Electronic trip unit protection functions : LSoI control type : Toggle mounting mode : Fixed
